VPX Profile Builder

Simplify your OpenVPX system design with the VPX Slot Profile Builder from Open.Tech by Amphenol. Instantly explore compatible VITA 65.0/65.1 slot profiles, filter by protocol or interconnect type, and visualize configurations—no spreadsheet digging required.

VPX Profile Builder Logo

Build Your VITA & SOSA-Aligned VPX Backplane or Plugin Card

Use our interactive VPX Profile Builder to explore our complete offering of VITA and SOSA-Aligned slot configurations.

Designing modular embedded systems that align with SOSA™ and VITA standards just got easier. The Open.Tech VPX Profile Builder is a web-based visualization and filtering tool built to streamline OpenVPX slot profile exploration. It enables engineers to interactively drill down into VITA 65-compliant profiles across multiple planes—data, control, expansion, and utility—while surfacing slot-level configuration options with coaxial, optical, and hybrid connector modules from VITA 66 and VITA 67 families.

Key features include:

  • Rapid filtering by signal plane, pipe width, protocol, and aperture style

  • View connector modules (e.g., NanoRF, SMPM, SMPS) for each slot profile

  • Compare backplane compatibility and connector module apertures

  • Download profile diagrams for build documentation

  • Align with SOSA-aligned profile sets for faster DOD acceptance

The tool supports engineers building rugged VPX systems for aerospace, defense, and high-performance embedded computing environments. From VITA 67.3 coaxial interconnects to VITA 66.5 RF/Optical hybrids, the Profile Builder helps you match physical and electrical design needs with speed and clarity.

Explore the builder: Open.Tech VPX Profile Builder



Check out our How To video: How to Use the Open.Tech VPX Profile Builder
